3 JAWS POWER CHUCK WITH LARGE THROUGH HOLE
Large View
3 JAWS POWER CHUCK WITH LARGE THROUGH HOLE
Features:

For use on modern CNC lathes.Positive Lok Power chucks are with large through holes suitable for both bar work and chucking of flange type parts.

The chucking power is transmitted by means of proven wedge system. Stable zigzag design work against high pressure and provide long tolerance and high accuracy at the same time.
SKU/Item Number : HTW-3X Price : On Demand
Technical features:

Rugged construction.

  • Large through hole.
  • High radial and axial true-running accuracy.
  • Direct lubrication of all wearing parts.
  • This type can be used for either hollow or closed center and the size of which depends on the connection part.
  • Straight recess mounting to DIN6353 or short taper mounting to DIN 55026 / 55021.


Catalogue Download
Download
  2D pdf 2D dwg 3D step
HTW3210-M
HTW3210-I
HTW2170-M
HTW2170-I
HTW3170-M
HTW3170-I
HTW4170-M
HTW4170-I
